E50-LH 41Nm 50mm-Centres

Crossed Axis Helical Gearboxes

Designed and Manufactured by Ondrives at our factory in the UK.

Sku
(Part No.)
Gear Ratio [i=]
Helix Direction
Centre Dist. [a]
Output Torque T₂max [Nm]
Output Torque T₂n [Nm]
Output Backlash j
Bore Diameter mm Ø H7
E50-1-19-LH1:1Left Hand50.00166.00≤0.75°19
E50-1-22-LH1:1Left Hand50.00166.00≤0.75°22
E50-1A-19-LH1:1Left Hand50.00166.00≤0.5°19
E50-1A-22-LH1:1Left Hand50.00166.00≤0.5°22
E50-1AR-19-LH1:1Left Hand50.00166.00≤0.16°19
E50-1AR-22-LH1:1Left Hand50.00166.00≤0.16°22
E50-1AR-LH1:1Left Hand50.00166.00≤0.16°20
E50-1A-LH1:1Left Hand50.00166.00≤0.5°20
E50-2-19-LH2:1Left Hand50.00166.00≤0.75°19
E50-2-22-LH2:1Left Hand50.00166.00≤0.75°22
E50-2A-LH2:1Left Hand50.00166.00≤0.5°20
E50-2A-19-LH2:1Left Hand50.00166.00≤0.5°19
E50-2A-22-LH2:1Left Hand50.00166.00≤0.5°22
E50-2AR-LH2:1Left Hand50.00166.00≤0.16°20
E50-2AR-19-LH2:1Left Hand50.00166.00≤0.16°19
E50-2AR-22-LH2:1Left Hand50.00166.00≤0.16°22
E50-3-19-LH3:1Left Hand50.00166.00≤0.75°19
E50-3-22-LH3:1Left Hand50.00166.00≤0.75°22
E50-3A-LH3:1Left Hand50.00166.00≤0.5°20
E50-3A-19-LH3:1Left Hand50.00166.00≤0.5°19
E50-3A-22-LH3:1Left Hand50.00166.00≤0.5°22
E50-3AR-LH3:1Left Hand50.00166.00≤0.16°20
E50-3AR-19-LH3:1Left Hand50.00166.00≤0.16°19
E50-3AR-22-LH3:1Left Hand50.00166.00≤0.16°22
E50-4-19-LH4:1Left Hand50.00166.00≤0.75°19
E50-4-22-LH4:1Left Hand50.00166.00≤0.75°22
E50-4A-LH4:1Left Hand50.00166.00≤0.5°20
E50-4A-19-LH4:1Left Hand50.00166.00≤0.5°19
E50-4A-22-LH4:1Left Hand50.00166.00≤0.5°22
E50-4AR-LH4:1Left Hand50.00166.00≤0.16°20
E50-4AR-19-LH4:1Left Hand50.00166.00≤0.16°19
E50-4AR-22-LH4:1Left Hand50.00166.00≤0.16°22
E50-5-19-LH5:1Left Hand50.00166.00≤0.75°19
E50-5-22-LH5:1Left Hand50.00166.00≤0.75°22
E50-5A-LH5:1Left Hand50.00166.00≤0.5°20
E50-5A-19-LH5:1Left Hand50.00166.00≤0.5°19
E50-5A-22-LH5:1Left Hand50.00166.00≤0.5°22
E50-5AR-LH5:1Left Hand50.00166.00≤0.16°20
E50-5AR-19-LH5:1Left Hand50.00166.00≤0.16°19
E50-5AR-22-LH5:1Left Hand50.00166.00≤0.16°22
E50-8-19-LH8:1Left Hand50.004011.00≤0.75°19
E50-8AR-22-LH8:1Left Hand50.004011.00≤0.16°22
E50-8-22-LH8:1Left Hand50.004011.00≤0.75°22
E50-8A-LH8:1Left Hand50.004011.00≤0.5°20
E50-8A-19-LH8:1Left Hand50.004011.00≤0.5°19
E50-8A-22-LH8:1Left Hand50.004011.00≤0.5°22
E50-8AR-LH8:1Left Hand50.004011.00≤0.16°20
E50-8AR-19-LH8:1Left Hand50.004011.00≤0.16°19
E50-10-19-LH10:1Left Hand50.004013.00≤0.75°19
E50-10-22-LH10:1Left Hand50.004013.00≤0.75°22
E50-10A-LH10:1Left Hand50.004013.00≤0.5°20
E50-10A-19-LH10:1Left Hand50.004013.00≤0.5°19
E50-10A-22-LH10:1Left Hand50.004013.00≤0.5°22
E50-10AR-LH10:1Left Hand50.004013.00≤0.16°20
E50-10AR-19-LH10:1Left Hand50.004013.00≤0.16°19
E50-10AR-22-LH10:1Left Hand50.004013.00≤0.16°22
E50-20-19-LH20:1Left Hand50.004015.00≤0.75°19
E50-20-22-LH20:1Left Hand50.004015.00≤0.75°22
E50-20A-LH20:1Left Hand50.004015.00≤0.5°20
E50-20A-19-LH20:1Left Hand50.004015.00≤0.5°19
E50-20A-22-LH20:1Left Hand50.004015.00≤0.5°22
E50-20AR-LH20:1Left Hand50.004015.00≤0.16°20
E50-20AR-19-LH20:1Left Hand50.004015.00≤0.16°19
E50-20AR-22-LH20:1Left Hand50.004015.00≤0.16°22
E50-40-19-LH40:1Left Hand50.004017.00≤0.75°19
E50-40-22-LH40:1Left Hand50.004017.00≤0.75°22
E50-40A-LH40:1Left Hand50.004017.00≤0.5°20
E50-40A-19-LH40:1Left Hand50.004017.00≤0.5°19
E50-40A-22-LH40:1Left Hand50.004017.00≤0.5°22
E50-40AR-LH40:1Left Hand50.004017.00≤0.16°20
E50-40AR-19-LH40:1Left Hand50.004017.00≤0.16°19
E50-40AR-22-LH40:1Left Hand50.004017.00≤0.16°22
E50-1-LH1:1Left Hand50.00166.00≤0.75°20
E50-10-LH10:1Left Hand50.004013.00≤0.75°20
E50-2-LH2:1Left Hand50.00166.00≤0.75°20
E50-20-LH20:1Left Hand50.004015.00≤0.75°20
E50-3-LH3:1Left Hand50.00166.00≤0.75°20
E50-4-LH4:1Left Hand50.00166.00≤0.75°20
E50-40-LH40:1Left Hand50.004017.00≤0.75°20
E50-5-LH5:1Left Hand50.00166.00≤0.75°20
E50-8-LH8:1Left Hand50.004011.00≤0.75°20
;
;
